For single- and multi-family houses, hotels, municipal buildings, industrial and agricultural halls, for those who seek an advanced and environment-friendly heating system we offer the technology for automatic biomass combustion in a step grate burner. In contrast to similar burners available on the market, the solution from the Company CWD Ltd enables automatic, safe and fully effective combustion of different types and fractions of biomass in one unit.

The unit for automatic biomass combustion in a step grate burner operates in the power range of 10 kW to 300 kW. The technology used in the boilers produced by the brand Cichewicz enables continuous combustion of different types of biomass, in the form of both pellets, briquettes and wood chips, irrespective of their grain size or moisture content. The combustion process is distinguished by the minimised generation of by-products, such as fly ash, scale or slag. A moving step grate operating in the burner automatically removes fly ash and slag from the furnace, while a unique air distribution system enables biomass combustion in the highest energy efficiency class. The burner can be used in new furnaces and boiler-houses, as well as to modernise the already existing heat sources, i.e. oiland coal-fired boilers. The heat generated is used to heat rooms and to produce domestic hot water. As an option, the burner can apply an advanced control technology which enables on-line management of the unit. Moreover, the solution includes automatic ignition and power modulation, reducing fuel consumption and ensuring energy savings.

Avantages of the solution:

• A universal system enabling the efficient combustion of most biomass types available on the market in one unit
• A moving step grate with a self-cleaning system
• Automatic ignition and unmanned, continuous and balanced operation of the burner
• High thermal efficiency and reduction of CO and dust emissions – a unit in the highest energy efficiency class
• A wide operating power range from 10 kW to 300 kW – even up to several MW in cascade systems. • A versatile application e.g. in boilers, heaters and different furnace types

The technology has been applied in the world, including e.g. three units with a total capacity of 1,050 kW used by a private clinic in northern Greece, where the total purchase costs of the units paid back already after two years from their installation. In turn, in Lithuania, in the area of Kaunas, two units with a total capacity of 700 kW heat a dozen or so municipal buildings in one of the local housing estates. This solution is also in operation in Germany, the Netherlands, Belgium, France, Ireland, Scotland, England, the United States and Ukraine. Thanks to the participation in the Greenevo program the step grate technology has been applied in the line of thermic waste transition with thermal and electrical energy recovery. The technology has been implemened in boiler-houses all around Poland as well as in Romania, Lithuania and Estonia. The company has also expanded the operation power range up to 700 kW.

Contact information:

CWD Sp. z o.o.
Rafał Cichewicz
14 Orlicz Dreszera St., Kozerki, 05-825 Grodzisk Mazowiecki
mob.: +48 609 213 932
e-mail: export@cichewicz.pl
www.grupa-cwd.pl
